CNC spring coiling machine, CNC-YF-8630, YF Spring Machinery
Available on back-order
Repair, replacement of parts, 24/7 technical support
Verification in real production conditions
Setting up and checking the functionality of the equipment
Training operators to work with the equipment and providing practical demonstrations of its functionality.
The CNC-YF-8630 classic spring coiling machine is designed for precision production of compression springs from wire with a diameter of 1.0 to 3.0 mm. Its six-axis control system and high-performance servomotors ensure stable and accurate operation.
The machine features two 1.2 kW cutting servos, a 4.5 kW wire feeding system, and independent diameter control servos. With a maximum output of 230 pcs/min and support for springs with an outer diameter up to 50 mm, it handles a wide range of spring designs.
Advantages:
- Supports wire diameters from 1.0 to 3.0 mm.
- High-performance servo feeding system for stability and speed.
- Up to 230 springs per minute.
- Compact frame: 1500×1000×1800 mm, weight — 800 kg.
- Power supply: three-phase 380 V.
Ideal for mass production of springs for electronics, appliances, tools, and toys. Contact us to learn more about the CNC-YF-8630.
Download brochure
