Crankshaft Grinding Machine, STH 1800S, SARITAS

The STH 1800S is a high-quality crankshaft grinding machine that provides precise processing and excellent surface quality to meet specific part requirements. Key components, including the table and grinding head, are made of durable gray cast iron, ensuring stability and reliability under heavy loads. The machine features a servo motor system for smooth grinding head movement and automatic table adjustment. With stepless spindle speed control and pneumatic operation, the STH 1800S offers convenient and user-friendly operation.

The machine is equipped with a touchscreen control panel, allowing operators to easily adjust processing parameters. Additionally, movement along the X and Y axes can be monitored on the digital display and controlled using joysticks, adding flexibility to the machine’s use. The STH 1800S is an ideal choice for repair workshops specializing in precision engine part processing.

Advantages:

• Stability and reliability thanks to high-quality gray cast iron construction.
• Simple adjustments via the touchscreen control panel.
• High processing precision with the servo motor system.
• Operational flexibility with options for both automatic and manual table control.
• Efficiency and convenience through pneumatic operation and stepless speed control.

Unique Features:

• Maximum distance between centers: 1900 mm.
• Maximum weight on centers: 300 kg (up to 600 kg with a steady rest).
• Maximum grinding wheel diameter: 710 mm.
• Chuck diameter: 200 mm.
• Quick hydraulic feed for grinding head: 150 mm.
• High-speed automatic table travel: 3000 mm/min.
• Grinding wheel motor power: 5.5 kW.

Contact us for a consultation on selecting and operating the machine. Book a free demonstration of the STH 1800S. Learn more about our products and their benefits.
