CNC spring coiling machine, CNC-YF-86100, YF Spring Machinery
Available on back-order
Full warranty of 12 months
Repair, replacement of parts, 24/7 technical support
Quality control
Verification in real production conditions
Exhibition center
The exhibit can be connected and demonstrated in operation.
Installation and adjustment
Setting up and checking the functionality of the equipment
The CNC-YF-86100 spring coiling machine is designed for processing thick wire ranging from 3.0 to 10.0 mm. With a maximum output of 150 pcs/min, this model is ideal for manufacturing large, industrial-grade springs efficiently.
Equipped with 6 axes, dual external diameter control motors (5.5 kW each), dual cutting units (7.0 kW each), and a powerful 9.0 kW wire feeding system, it delivers consistent performance under demanding conditions.
Advantages:
- Handles springs with a max outer diameter of 140 mm.
- High-power servo motors for wire feed and cutting.
- Stable and precise operation.
- Dimensions: 3000×2500×2200 mm, weight — 5800 kg.
- Power supply: 380 V ±10%, 50 Hz.
Ideal for high-volume production of large compression springs.
