Valve grinding machine, VGX, AZ

The VGX valve grinding machine is designed for precise restoration of the valve face and stem tip in professional engine shops. Smooth speed control delivers consistent surface finish and repeatable results.

Advantages:

• Variable valve rotation speed for optimal grinding conditions.
• Variable grinding wheel speed to match material and valve size.
• Adjustable spindle head tilt 15°–60° to grind at the required angle.
• Secure clamping with a collet sleeve.
• V-shaped ways and a valve stop for fast, repeatable repositioning.
• Stem tip grinding (tipping) for accurate lash adjustment.
• Cooling system for stable geometry and longer wheel life.

Standard Equipment:

• Variable valve spindle speed.
• Grinding wheel speed control system.
• Grinding wheel 150×25×25 mm.
• Cup grinding wheel 80×30×15 mm.
• Support for diamond dresser (diamond not included).
• Valve stem support for grinding.
• Cooling system.
• Service tools.
• Operating manual.

Optional Accessories:

• AZ667 — 3-collet system for valves Ø6–16 mm.
• AZ411 — diamond and base, 0.40 ct.
• AZ659 — collet sleeve for short valves, Ø4 mm.
• AZ660 — collet sleeve for short valves, Ø5 mm.
• AZ661 — collet sleeve for short valves, Ø5.5 mm.
• AZ662 — collet sleeve for short valves, Ø6 mm.
• AZ663 — collet sleeve for short valves, Ø7 mm.
• AZ664 — collet sleeve for short valves, Ø8 mm.
• AZ665 — collet sleeve for short valves, Ø9 mm.
• AZ666 — collet sleeve for short valves, Ø10 mm.
• AZ685 — rocker arm grinding device.
• AZ686 — steel plate base.

Contact us to configure the VGX to your tasks and to arrange a live demo.
