Hydraulic Valve Guide Press, TGP-1200, Tendtool

TGP 1200 is a hydraulic press designed for quick, safe, and easy valve guide replacement. This machine is equipped with a powerful hydraulic cylinder that enables precise assembly and disassembly of engine valves. TGP 1200 is ideally suited for professional use, providing efficiency and reliability in the process of valve guide replacement.

The standard equipment includes tools for valve guide removal, a set of assembly tools, and compression jaws of various sizes, offering flexibility for different tasks.

Advantages:

• Fast and safe valve guide replacement.
• Powerful hydraulic cylinder for precise valve assembly and disassembly.
• Sturdy construction for durability and reliability.
• Flexible tool set for a variety of tasks.

Features:

• Worktable length: 1200 mm.
• Horizontal movement: 1100 mm.
• Vertical movement: 150 mm.
• Upper cylinder movement: 230 mm.
• Working pressure up to 200 bar with adjustable settings.
• Motor power: 1.5 kW.
• Oil tank capacity: 9 liters.
• Power supply: 380 V, 50 Hz, 3-phase.
• Machine dimensions: length 1370 mm, width 930 mm, height 1850 mm.
• Weight: 400 kg.

Contact us for a consultation on selecting and operating the machine. Request a free demonstration of the TGP 1200 in action. Learn more about our products and their unique benefits.
