Hydraulic Honing Machine, STH 450, SARITAS

STH 450 is an automatic hydraulic honing machine specifically designed for honing engine cylinder liners and similar parts with maximum precision and according to the required technical specifications. The work-head body and slides are made of high-quality cast iron resistant to vibration, ensuring stability and high machining quality. All machine functions are controlled from a single control panel mounted on a hook for convenient operation from various angles. The panel is equipped with digital indicators, a pressure gauge, rotation speed adjustment, and precise hydraulic feed adjustment. The freely movable lower table facilitates engine block centering and significantly reduces setup time. Independent adjustment of the honing head’s rotation speed and feed allows achieving optimal crosshatch angles on the machined surface. The magnetic braking system of the honing head at any position prevents damage to the crosshatch pattern.

Advantages:

• High stability thanks to the high-quality cast iron body.
• Convenient control from a single panel with digital indicators and a pressure gauge.
• Quick centering with the movable lower table.
• Flexible adjustment of rotation speed and feed for optimal honing angles.
• Crosshatch protection through the magnetic braking system.

Features:

• Honing diameter range: 40-250 mm
• Maximum workpiece height: 700 mm
• Adjustable spindle rotation speed: 0-250 rpm
• Precision hydraulic feed: with independent adjustment.
• Magnetic braking: to preserve crosshatch pattern quality.

Contact us for a consultation on choosing and operating the machine. Book a free demonstration of the STH 450 and learn more about our solutions.
