Hydraulic Honing Machine, STH 400, SARITAS
Available on back-order
Repair, replacement of parts, 24/7 technical support
Verification in real production conditions
The exhibit can be connected and demonstrated in operation.
Setting up and checking the functionality of the equipment
STH 400 is an automatic hydraulic honing machine specifically designed for honing engine cylinder liners and similar parts with maximum precision and according to the required technical specifications. The work-head body and slides are made of high-quality cast iron resistant to vibration, ensuring stability and high machining quality. All machine functions are controlled from a single control panel mounted on a hook to allow operation from various angles. The panel is equipped with digital indicators, a pressure gauge, rotation speed adjustment, and hydraulic feed precision adjustment. The freely movable lower table facilitates engine block centering and significantly reduces setup time. Independent adjustment of the honing head’s rotation speed and feed allows achieving optimal crosshatch angles on the machined surface. The magnetic braking system of the honing head at any position prevents damage to the crosshatch pattern.
Advantages:
- High stability thanks to the high-quality cast iron body.
- Full control from a single control panel with digital indicators and pressure gauge.
- Quick centering with the movable lower table.
- Flexible adjustment of rotation speed and feed for optimal honing angles.
- Crosshatch protection through the magnetic braking system.
Features:
- Honing diameter range: 40-250 mm
- Maximum workpiece height: 700 mm
- Spindle rotation speed: 0-250 rpm
- Hydraulic feed system: with high-precision adjustment.
- Magnetic braking: to protect the crosshatch structure.
Contact us for a consultation on choosing and operating the machine. Book a free demonstration of the STH 400 and learn more about our solutions.
Download brochure
