High-precision CNC gantry milling machine, MM-FP4030, MAXNOVO

The MM-FP4030 is a high-performance CNC gantry milling machine from MAXNOVO MACHINE, designed for machining extremely heavy components with exceptional precision. With a working table size of 4000 x 2200 mm and a maximum load capacity of 15 tons, this machine is perfect for demanding industrial applications. It is CE safety certified, ensuring compliance with rigorous safety standards.

Advantages:

• Exceptional Precision: Advanced design ensures high accuracy in machining processes.
• Modern Design: State-of-the-art structure ensuring efficiency and effectiveness.
• Efficiency and Productivity: Capable of handling heavy-duty tasks with ease, providing high output and reliability.

Key Features:

• Traveling Worktable and Fixed Gantry: Allows machining of large, heavy components with stable precision.
• Double-Column Structure: Ensures high rigidity and consistent accuracy.
• Robust Worktable: 4000 x 2200 mm dimension with a load capacity of 15,000 kg.
• Large Travel Distances: X/Y/Z axis travel of 4200/3150/1000 mm.
• Linear and Box Ways: Roller-type linear guides on X and Y axes and box guides on Z axis for superior accuracy.
• Hardened and Ground Guides: All guides hardened to HRC 50 and precision-ground.
• Precision Ball Screws: Installed on all axes with preloaded bearings to maintain high-speed travel.
• Quality Cast Iron Construction: Major components like the base, worktable, and columns made from high-quality Meehanite cast iron.
• Stable and Rigid Design: The double-column design provides excellent rigidity for heavy-duty operations.
• Large Sliding Doors: Facilitates easy access and convenient tool handling.
• Wide Work Area: Accommodates large workpieces effectively.
• Automatic Tool Changer: 24-tool automatic changer included for efficient operation.
• Optional CNC Control Systems: SIEMENS and FANUC control systems available.

Contact us for a consultation on selecting and operating the MM-FP4030 milling machine. Schedule a free demonstration of the MM-FP4030. Learn more about our products and their advantages
