Connecting Rod Boring Machine, BR650, AZ

The BR650 is a connecting-rod boring and grinding machine featuring planetary grinding adjustable during the operation. It is engineered to combine boring and grinding in one setup, built on a rigid cast-iron base. The boring spindle speed is variable via an electronic variator with digital readouts. The con-rod holding square offers variable longitudinal speed with a reversal limit switch, plus crosswise movement for easy centering. A micrometric grinding-wheel eccentricity device refines finish quality. A coolant system with electric pump is included.

Advantages & Features:

• Adjustable planetary grinding during the process.
• Variable boring spindle speed with electronic variator and digital indications.
• Rod-holding square with variable longitudinal speed and reversal limit switch.
• Crosswise movement for quick, accurate centering.
• Micrometric device for wheel eccentricity; cast-iron base; coolant with electropump.

Standard Equipment (BR650):

• Electronic variable-speed drive for boring and grinding
• AZ252 Set of 7 grinding wheels for cast iron and steel
• AZ935 Set of 8 tools
• Grinding-wheel dressing device (no diamonds)
• AZ734 Tool setting device
• AZ732 Centering device without circular-scale gauge
• AZ390 3 L of coolant
• Coolant system
• Service tools and Operating manual

Dial gauges for the standard kit (choose as required):

• AZ708 Ø40 mm
• AZ708P Ø1.57″, resolution 0.001″
• AZ721 Tool measuring device in millimetres
• AZ721P Tool measuring device in inches
• 320333 Push-type dial gauge Ø38 mm

Optional Accessories:

• AZ711 Internal gauge for bushings Ø35–105 mm (without dial gauge)
• AZ714 Internal gauge for bushings Ø100–220 mm (without dial gauge)
• AZ707 Dial gauge Ø60 mm, 0.01 mm resolution
• AZ707P Dial gauge Ø2.36″, 0.0005″ resolution
• AZ520 Boring head Ø105–160 mm
• AZ832 Tool grinder with stand
• AZ786 1-axis linear position sensor and digital indicator

Contact us to configure the BR650 for your workflow and book a live demonstration.
